3 Axle Step Deck Curtain Side Trailer

3 Axle Step Deck Curtain Side Trailer

15000 USD

3 axle step frame curtain side trailer is very convenient for loading and unloading of goods.

SKU: 3 Axle Step Deck Curtain Side Trailer
MPN: TITAN9418006
Brand: TITAN

Description of step deck curtain side trailer:

3 axle step frame curtain side trailer is very convenient for loading and unloading of goods.

curtain side car trailer can be rainproof, dustproof, heat-proof, safe and environmentally friendly.

3 Axle Step Deck Frame Curtain Side Car Trailer for Sale

3 Axle Step Double Drop Deck Frame Curtain Side Car Trailer for Sale

3 Axle Step Deck Frame Curtain Side Car Trailer for Sale

3 Axle Step Double Drop Deck Frame Curtain Side Car Trailer for Sale

3 Axle Step Deck Frame Curtain Side Car Trailer for Sale



Specifications of step frame curtain side trailer:

Overall dimension: 12500x2500x4380mm

Payload: 40, 000kg

Side: made of reinforced PVC curtains

Axles: 3 axles, 13T/16T ,FUWA/ BPW/ TITAN Brand

Tire: 12 units, 12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5

Suspension: Mechanical suspension(Germany or America type)

Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)

Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)

Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel

Platform: 3mm-thick checkered plate

Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank

Valve: WABCO valve (specially intended for oversea market)

ABS: Optional

Light: LED light (specially intended for oversea market)

Voltage: 24V

Socket(Receptacle): 7-pin Socket (for 7 wire harness)

Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)

Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats



How to use a step deck curtain side trailer?

If you’re buying, using or hiring a double deck curtain side trailer for sale, then you need to know how to open and close them and what to check for as it can be dangerous:

Don’t open a step deck curtain side trailer which is bulging – freight could have moved and might fall on you. Open it from the back or the opposite side to check

In strong or gusty winds, open the lee side of the double deck curtain side trailer first

When opening any curtain in gusty winds, take care as the wind can take the curtain pole and swing it into your head, knocking you out

Loose buckles can flap around and hit passing cars – make sure all buckles are tight

Make sure you check the rating and the expiry date on any curtains to make sure they will be fine for what double drop curtain side trailer is carrying

Make sure you have enough load securing restraints available to restrain the load properly

Watch where drop deck curtain side trailer for sale is going while you’re walking backwards as you slide the curtains back – it’s easy to trip.
